ELECTRONICS ASSEMBLY SERVICES
SURFACE MOUNT
UNITED EAGLE GROUP offers printed circuit board stuffing in accordance with three classes of the Acceptability of Electronic Assemblies (IPC-A-610). Our SMT Assembly lines provide either RoHS compliant lead-free in the printed board assembly process. Yours/ours printed circuit boards are assembled with exceptional quality, utilizing the latest technology in surface mount equipment.
THROUGH HOLE
UNITED EAGLE GROUP offers cost effective through-hole assembly, either RoHS compliant lead-free assemblies or traditional tin-lead solder in the printed board assembly process. We cover the full range, from the simplest to the most complex through-hole assemblies.
CABLE & HARNESS ASSEMBLY
UNITED EAGLE GROUP cable and harness assemblies are all hand assembled by our skilled technicians to original OEM specifications to ensure compliance. Always a perfect fit in each and every job. This includes using automated and semi/automated crimpers.
MAGNETICS ASSEMBLY
UNITED EAGLE GROUP enjoys a depth and breadth of experience in magnetics manufacturing spanning over 22 years. We use the highest quality methods and ideal materials to manufacture your transformer, inductors and toroids under the most optimum conditions. Our team of experts bring decades of design and manufacturing experience to the forefront on each project and work under our strict IPC standards for quality workmanship.
SURFACE MOUNT
TECHNICAL DATA
Performance: 6000 components/hour 18000 glue dots/hour
Program capacity: 8000 components or operating maximum
Configuration: (1) head moving (x/y/theta); 4 nozzles placing SMD components on PCB
Placement capacity: From t/430um to 100urn
COMPONENTS
Dimensions: from 0.5mm x 1mm to 50mm x 50mm
Maximum height: 12mm
Types: chips, SOT, SOD, MELFS, MINIFELPS, SOIC, PLCC, QFP, PQFP, BGA
Fine pitch: 0.4mm
FEEDERS CAPACITY
Capacity: 144.8mm tapes (72 double tape feeders) or 198.8mm tapes (6 tape trolleys)
Any SMD component that can be picked up with a vacuum nozzle can be placed.
Surface Mount (Line 1 & Line 2)
Workmanship standards based on IPC-A-610
RoHS
SMT for all non-lead finishes and for fully RoHS and non-RoHS compliant boards.
THROUGH HOLE
• Simple to complex through-hole assembly
• Assembly lines designed to minimize product travel and operator movement
• Documentation and in-process inspections for quality assurance
• Workmanship standards based on IPC-A-610
• High-density multilayer PCBs or miniature hand-soldered assemblies
UNITED EAGLE GROUP meets its customers exact requirements using multiple, linked continuous-flow production lines, dedicated aqueous and no-clean solder chemistry, potting, conformal coating and final (box build) product assembly all orchestrated by a highly-trained and dedicated staff.
Our through-hole assembly capability provides our customers with a cost-effectIve and highly flexible contract manufacturing solution.
CABLE & HARNESS ASSEMBLY
Our cable and harness assemblies are all hand assembled to original OEM specifications to ensure compliance to specification and a perfect fit Our skilled technicians ensure the following foul criteria are met on each and every Job:
• Wire gauge. length, color and tape match original specification
• Rigid quality control standards are adhered to throughout the process
• The harness you receive is guaranteed to look, fit and function as original
• Workmanship standards based on IPC I W1-1MA-A-620
Were accustomed and fully prepared to handle both low volumes (pigtails and prototypes) and medium to high production volumes.
MAGNETICS ASSEMBLY
UNITED EAGLE GROUP enjoys a depth and breadth of experience in magnetics manufacturing spanning some 22 years.
Our areas of expertise include:
• Transformer and magnetic assembly manufacturing
• Winding inductors and transformers with bobbins and toroids
• Varnish, dipped, impregnated and air or oven-cured processing
• Full Inspection and testing to customer specifications
We use the highest quality methods and ideal materials to manufacture your transformer, inductors and toroids under the most optimum conditions. Our team of experts bring decades of design and manufacturing experience to the forefront on each project and work under our strict IPC standards for quality workmanship.
Send us your project and RFQ.
MOQ 500 PCs.
